LX12 MIXER

12-channel mixer with Bluetooth®, USB,
FX, and recording software

LX12 MIXER

Specifications

Frequency Response:

 20Hz–22kHz

THD:

 0.009%

Preamp Noise (EIN):

 -121dB

Residual Output Noise:

 -91dB

Common Mode Rejection Ratio (CMRR):

 >68dB @ 1kHz

Crosstalk (Adjacent Channels):

 –88dB

Crosstalk (Same Channel, Stereo Separation):

 –82dB

Input Gain Control Range:

 +15dB to +63dB

Phantom Power:

 +48V

EQ HIGH:

 ±12dB@ 10 kHz

EQ MID:

 ±15dB@ 2.5 kHz

EQ LOW:

 ±12dB@ 100Hz

Output Level (Max):

 +22dBu

Maximum Input Level (Mic):

 +6dBu (with –26dB PAD)

Maximum Input Level (Line Input):

 +21dBu at Unity Gain

Maximum Input Level (Aux Input):

 +6dBu at 15dB Level max

Input Impedance (Mic):

 2kΩ, balanced

Input Impedance (Line Input):

 10kΩ, balanced

Input Impedance (Aux Input):

 10kΩ, balanced

Outer Impedance (Mic):

 120Ω

Outer Impedance (Control Room, Rec Out):

 120Ω

Outer Impedance (Headphones):

 100Ω

VU Meters:

 Clip (+16), +10, +6, 0, -3, -6, -10, -20dB

Dimensions LxWxH:

 11.64” x 11.58” x 2.40”

Weight Net (without PSU):

 3.2 lbs
LX12

LX12

12-CHANNEL MIXER WITH BLUETOOTH®, USB, FX & RECORDING SOFTWARE

LX12

12-CHANNEL MIXER WITH BLUETOOTH®, USB, FX & RECORDING SOFTWARE

SKU

quotation marks

HIGH PERFORMANCE AND GREAT RELIABILITY”

“If you’re thinking about getting a mixer, and you want to get the best bang for the buck that’s still going to give you high performance and great reliability, this is the video you’re going to want to watch.”

Robin details why the LX12 should be your next mixer.

HARDWARE FEATURES

4 PREMIUM MIC PREAMPS

Mix up to 4 microphones at once, with phantom power available for condenser mics

COMPRESSORS

4 compressors give vocals and dynamic instruments a polished, produced sound

FX ENGINE

24-bit multi-core FX engine with 24 adjustable digital FX

BLUETOOTH® AUDIO INPUT

Stream wireless audio from any Bluetooth device

USB AUDIO

Mix in USB playback, and record a stereo mix or 2 mono sources to USB

SOLO FEATURE

Push-button Solo feature conveniently mutes all other channels

MAIN AND MONO OUTPUTS

XLR Main outputs for connecting to pro-standard equipment, mono out for mono setups

MONITOR, CONTROL ROOM & HEADPHONE OUTPUTS

Balanced 1/4″ Monitor Output, balanced 1/4″ Control Room Outputs, and stereo headphone output

STEREO RECORD OUT

1/8” Stereo record output for connecting to mobile devices and 1/4” headphone output

EQ CONTROLS

3-Band EQ for detailed tone adjustment

PAN/BALANCE CONTROLS

Pan/Balance controls to adjust stereo placement

white line





READY TO GO WHEREVER YOUR MUSIC TAKES YOU

  • Bluetooth for easy streaming from smartphones and devices
  • 4 Premium Microphone Preamps with Compressors
  • Built-in 2×2 computer USB audio interface – recording software included
  • Guitar input, guitar amp recording software
  • Monitor Mix Bus to give on-stage performers a custom mix
  • 24 Built-in adjustable FX
black line



DAW SOFTWARE

MAC & Windows compatible

Powerful and creative recording workstation software with full compatibility with all popular instruments and FX plug-ins.

See a full-size version of the software

black line



GUITAR AND BASS TOOLS

MAC & Windows compatible

Virtual miking, power amp simulation and studio-grade post effects. The ideal way to record your guitar/bass with consistent and rich tone.

See a full-size screenshot of the software

white line



PROFESSIONAL INPUT CONNECTIVITY

  • 4 High-headroom, low-noise microphone preamps
  • 48V Phantom power for condenser microphones
  • 4 XLR 1/4″ combo inputs support a wide range of sources
  • 3 stereo 1/4” inputs for line-level sources
  • 1 stereo 1/8” input for connecting mobile devices
  • Guitar input with Hi-Z switch for optimized impedance
  • -26dB Pads and 80Hz High-Pass filters minimize clipping and low-frequency rumble
  • 1/4″ FX footswitch input for muting FX remotely
  • Stereo USB audio to mix in USB playback, and record a stereo mix or 2 mono sources to USB
