LV14 MIXER

14-channel mixer with Bluetooth®

LV14 MIXER

Specifications

Onboard 24-bit Digital FX:

 16 presets with parameter adjust

Phantom Power:

 48V DC (CH1-6)

Input Channels:

 6 Mono MIC/LINE (XLR ¼” combo), 3 Stereo LINE (1/4”), 1 Stereo 1/8”, 1 Bluetooth

Output Channels:

 1 Stereo MAIN OUT (XLR), 1 Stereo CTRL RM (1/4″), 1 Stereo REC OUT (1/8”)

Monitor Output:

 1 Mono (1/4”)

Headphone Output:

 1 Stereo (1/4”)

26dB PAD:

 4 (CH1-6)

80Hz High-Pass Filter:

 4 (CH1-6)

Guitar Hi-Z Input:

 1 (CH 7|8)

FX ON/OFF Footswitch:

 1 (1/4″)

Internal FX Send:

 1

External Aux/Monitor Send:

 1

EQ HIGH:

 ±12dB@ 10 kHz (shelving)

EQ MID:

 ±15dB@ 2.5 kHz (peaking)

EQ LOW:

 ±12dB@ 100Hz (shelving)

LED Meters:

 6-Segment (CLIP, +6, 0, -6, -10, -20)

Dimensions WxDxH:

 17.12” x 11.65” x 4.06”

Weight Net (without PSU):

 4.03 lbs
LV14

LV14

14-CHANNEL MIXER WITH BLUETOOTH®

LV14

14-CHANNEL MIXER WITH BLUETOOTH®

SKU

quotation marks

A LOT OF USE CASE SCENARIOS”

If you’ve got a gig, and you’ve got a little band, whether it’s a club, a nightclub or a restaurant… either of these will work very nicely in those situations.”

Keithron gives an overview of the LV12 and LV14 mixers.

quotation marks

A REALLY GOOD THING”

That makes this, as a recorder, as good as buying an audio interface.”

Robin runs down the features and benefits of the LV14 mixer.

HARDWARE FEATURES

6 PREMIUM MIC PREAMPS

Mix up to 6 microphones at once, with phantom power available for condenser mics

USB AUDIO

Mix in USB playback, and record a stereo mix or 2 mono sources to USB

MONITOR SEND

Monitor send controls for setting up a dedicated monitor mix

FX PROCESSOR

FX send controls route channel signals to the internal FX processor

BLUETOOTH® AUDIO INPUT

Stream wireless Bluetooth audio from any Bluetooth device

SOLO FEATURE

Push-button Solo feature conveniently mutes all other channels

MAIN AND MONO OUTPUTS

XLR Main outputs for connecting to pro-standard equipment, mono out for mono setups

MONITOR, CONTROL ROOM & HEADPHONE OUTPUTS

Balanced 1/4″ Monitor Output, balanced 1/4″ Control Room Outputs, and stereo headphone output

STEREO RECORD OUT

1/8″ Stereo Record Output for connecting to mobile devices and 1/4″ Headphone Output

EQ CONTROLS

3-Band EQ for detailed tone adjustment

16 FX

16 FX including an array of reverbs and FX combinations

FX ADJUST

FX Parameter Adjust knob for fine-tuning of FX

black line



YOUR SOUND, YOUR SETUP, YOUR SOLUTION

  • Bluetooth Audio Input
  • 6 Premium Microphone Preamps
  • Built-in 2×2 computer USB audio interface
  • Guitar Input
  • Built-In FX
  • Monitor Mix Bus

white line



PROFESSIONAL INPUT CONNECTIVITY

  • 6 High-headroom, low-noise microphone preamps
  • 48V Phantom power for condenser microphones
  • 6 XLR 1/4″ combo inputs support a wide range of sources
  • Guitar input with tone-preserving Hi-Z switch
  • -26dB Pads and 80Hz High-Pass filters minimize clipping and low-frequency rumble
  • Stereo USB audio input and output
