LV12 MIXER

12-channel mixer with Bluetooth®

LV12 MIXER

Specifications

Onboard 24-bit Digital FX:

16 presets with parameter adjust

Phantom Power:

48V DC (CH1-4)

Input Channels:

4 Mono MIC/LINE (XLR ¼” combo), 3 Stereo LINE (1/4”), 1 Stereo 1/8”, 1 Bluetooth

Output Channels:

1 Stereo MAIN OUT (XLR), 1 Stereo CTRL RM (1/4″), 1 Stereo REC OUT (1/8”)

Monitor Output:

1 Mono (1/4”)

Headphone Output:

1 Stereo (1/4”)

26dB PAD:

4 (CH1-4)

80Hz High-Pass Filter:

4 (CH1-4)

Guitar Hi-Z Input:

1 (CH 5|6)

FX ON/OFF Footswitch:

1 (1/4″)

Internal FX Send:

1

External Aux/Monitor Send:

1

EQ HIGH:

±12dB@ 10 kHz (shelving)

EQ MID:

±15dB@ 2.5 kHz (peaking)

EQ LOW:

±12dB@ 100Hz (shelving)

LED Meters:

6-Segment (CLIP, +6, 0, -6, -10, -20)

Dimensions WxDxH:

10.67” x 9.65” x 2.28”

Weight Net (without PSU):

2.97 lbs
